04-Feb-2022

Rebar cage with anchor bolts and template

You can see the arrow on top of the bolt pattern template, this will allow accurate positioning
of the bolt pattern by pointing it directly at the stake with white top there in the distance
this stake is positioned very exactly true south of the centre of the footing hole.
