technical corner
My second own processed tube and some mess around :)
:: Bending and pumping in 2020 ::
Xenon and Krypton transfer systems
Back in USSR age they used non-activated electrodes. Compare size - old (20mA) rated and modern EGL 'trodes (20-30mA)
My neon manifold (A few years ago already!)
Tubes from USSR age (white & gold) and my own recent (pink)
My first two tubes I made completely myself, around December 2012
:: Toy nightlight dissection and waveform ::
:: Tube voltage - magnetic transformet ::
:: sterilizer ::
:: 220V powered cold cathode UV phosphor tester ::
:: My German style gas-oxygen-air glasblaeser-brenner. ::
:: royer ::
:: NeonPro HF 7.5K30 transformer teardown and schematics ::
