Het vangsysteem - Brakesystem

Links zie je het ankerpunt en bovenaan het trekuiteinde. Hij wordt naar beneden getrokken door de verticale houten balk die verbonden is met de grote horizontale vangbalk.

You see the achorpoint at the left and the pulling end on top. It is pulled down by the vertical wooden beam that is connected with the large horizontal brakebeam.
