18" Pull Saw Sharpening

The plan was to improve the performance of this old pruning saw.

The good part, the saw cuts twice as fast after setting and sharpening.

The other part when compared to modern saws is that it may not compare to them because; the saw steel is very soft and may not hold an edge long, there are fewer teeth and the rake angle is not what is used in current saws.

In the end it works much better then it did but for cutting larger logs I'm not going to replace my vintage crosscut saw with this saw. What took about four minutes with this saw would take about 1/2 minute with a good crosscut saw.
18 Pruning/Pull Saw
18" Pruning/Pull Saw		 Testing cutting speed - 30 sec. two hand, 63 sec one hand
Testing cutting speed - 30 sec. two hand, 63 sec one hand		 Before sharpened- Note pointed teeth
Before sharpened- Note pointed teeth		 Before sharpened, Set was 0.008 to 0.045
Before sharpened, Set was 0.008" to 0.045"
Checking Set, Set to 0.015
Checking Set, Set to 0.015"		 Special set gauge for short teeth
Special set gauge for short teeth		 In saw vice
In saw vice		 Sharpened, Note tips filed off
Sharpened, Note tips filed off
After Sharpened - 17 sec. two hands, 30 sec. one hand
After Sharpened - 17 sec. two hands, 30 sec. one hand		 Cut a 11 Frozen Log - About 4 minutes
Cut a 11" Frozen Log - About 4 minutes		 Corona Razor Tooth Pruning Saw - 10° Rake Angle
Corona Razor Tooth Pruning Saw - 10° Rake Angle		 Silky Hayauchi Telescoping Pole Saw - 10° Rake Angle
Silky Hayauchi Telescoping Pole Saw - 10° Rake Angle
Silky Hayauchi Telescoping Pole Saw Detail
Silky Hayauchi Telescoping Pole Saw Detail		 Cutting Speed for different saws
Cutting Speed for different saws		 Fanno K24 Saw
Fanno K24 Saw		 Needed Jointing
Needed Jointing
Morin gauge
Morin gauge		 Wood wedges to flex file
Wood wedges to flex file		 Jointing concave surface
Jointing concave surface		 Cuts like Crazy (Nearly twice as fast)
Cuts like Crazy (Nearly twice as fast)
