M1873 Maynard Creedmoor

An interesting 1873 No. 14 Maynard Creedmoor Long Range Rifle with the receiver modified for a Hadley Device. 32-inch tapered round barrel in .44-100 1873 Maynard. Maynard Patent Rack and Pinion Long Range Tang Sight. Front Sight base from a Remington Windgauge Front Site. Beautiful wood in the Creedmoor shotgun butt, fully checkered pistol grip attached to the lever, a truly wonderful addition to any single shot rifle collection.

Overall View - Left Side	Overall View - Right Side	Double Diamond Checkering Pattern	1873 Breech - with barrel in position for loading	Detail - 1873 Breech with Hadley Device Removed and Action Closed	1873 .44-100 Cartridge and Receiver
Rim-Fire Hadley Device - again not installed	Hadley Device in place with Barrel in position for loading	Buttstock - Beautiful Wood Grain	Buttstock - Opposite Side	Sight Stud Partially Unscrewed From Tang	Tang Holes Showing Original Location Of Thumb Piece Hole
Maynard Patent Long Range Tang Sight Rack and Pinion	Maynard Patent Long Range Rack and Pinion Tang Sight With Thumbpiece In Place	Thumbpiece - Side View	Remington Windgauge Sight Base	1873 Marking on Breech Piece	Disassembled View
Disassembled Pistol Grip With Lever Insert and Screw	Maynard Patent Long Range Rack and Pinion Tang Sight Graduation Marking	Comparison of Eyecups	Patent Marking On Tang Sight Staff	Comparison of Long Range and Mid Range Sight Staff	L-R - 550 PP Bullet, .44-100 1873, .40-70 1873, .40-60 1873 Original, .35-40 1865
Same As Previous - Only PP Bullet Inserted In Case
